Deep drilling diameter

mm

2.5 - 20

4 - 30

4 - 30
(Opt. 38)

4 - 30
(Opt. 38)

6 - 38

Drilling depth max.

mm

600

1.000

1.300

1.600

2.000

Table area

mm

720*600

1.160*900

1,500*900

1,800*1,250

2,100*1,300

X-axis, table across

mm

600

1.000

1.350

1.600

2.200

Y-axis, drilling unit vertical

mm

600

1.000

1.000

1.000

1,150 (opt. 1,500)

Z-axis, deep drill axis

mm

600

1.000

1.300

1.600

2.000

Spindle speed

min-1

6.000
(Opt. 8,000)

6.000
(Opt. 8,000)

6.000
(Opt. 8,000)

6.000

6.000

Spindle

kw

5.5 / 7.5

7.5 / 11

7.5 / 11

11.5 / 15

11.5 / 15

Coolant pressure

Bear

80

80

80

80

80

Table pollution central

kg

3.000

5.000

7.500

10.000

18.000

CNC control

Syntec 10a
